TRACO POWER - THP 3-2422 - Isolated Through Hole DC/DC Converter, Medical, 4:1, 3 W, 2 Output, 12 V, 125 mA
- No. of Outputs: 2 Output
- Output Power Max: 3W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 125mA
- Output Voltage - Output 2: -12V
- Output Current - Output 2: 125mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: THP 3 Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 40V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.3mm
- Height: 10.7mm
- Depth: 31.8mm
- SVHC: No SVHC (27-Jun-2018)
- Approval Bodies: CSA C22.2 No. 601, EN 60601, IEC 60601, UL 60601
- Approvals & Standards: CSA 22.2 No. 60601, IEC 60601, UL 60601
- Efficiency: 83%
- Isolation Voltage: 4kV
- No. of Outputs: 2Outputs
- Output Current - Max: 125mA
- Output Voltage +: 12VDC
- Output Voltage -: 12VDC
- Power Rating: 3W
- Supply Voltage: 24V
