TRACO POWER - THV 12-500P - Non Isolated POL DC/DC Converter, High Voltage, ITE, 3 W, 0 V, 500 V, 6 mA, Adjustable
- Output Power Max: 3W
- Output Voltage Min: 0V
- Output Voltage Max: 500V
- Output Current Max: 6mA
- DC / DC Converter Output Type: Adjustable
- DC / DC Converter Type: SIP
- Input Voltage DC Min: 10.8V
- Input Voltage DC Max: 13.2V
- Height: 19.8mm
- Depth: 110mm
- Width: 12mm
- Product Range: -
- SVHC: No SVHC (27-Jun-2018)
- DC / DC Converter Mounting: Through Hole
- No. of Outputs: 1Outputs
