TIM1000 Transformer, Isolating, 1kVA Block

BLOCKUGS :TIM1000 Code de commande:1177115

Prix:
Prix ​​promotionnel€622,66

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 3 produits disponibles

Documents et téléchargements

description

BLOCK - TIM1000 - DIN Rail Mount Transformer, Encapsulated, Safety Isolating, 230V, 2 x 115V, 1 kVA, Class 2

  • Power Rating: 1kVA
  • Secondary Voltages: 2 x 115V
  • Current Rating: 4.35A
  • Isolation Transformer Primary Voltages: 1 x 230V
  • Plug Type: -
  • Product Range: -
  • SVHC: No SVHC (12-Jan-2017)
  • AC Power: 1000VA
  • Approval Bodies: DIN, EN, IEC, VDE
  • External Depth: 200mm
  • External Length / Height: 165mm
  • External Width: 283mm
  • Fixing Centres LxW: 245 x 148
  • Height: 165mm
  • Input Voltage: 230V
  • Insulation Class: B
  • Operating Temperature Max: 40°C
  • Output Voltage: 115V
  • Primary Voltages: 1 x 230V
  • Protection Type: IP20
  • Secondary No Load Voltage: 1.02V
  • Secondary Power: 1kVA
  • Single Primary Voltage: 230V
  • Supply Frequency Max: 60Hz
  • Supply Frequency Min: 50Hz
  • Test Voltage: 3750VAC
  • Transformer Type: Isolation
  • Type: Enclosed
  • Weight: 17.1kg
