BLOCK - TIM800 - DIN Rail Mount Transformer, Encapsulated, Safety Isolating, 230V, 2 x 115V, 800 VA, Class 2
- Power Rating: 800VA
- Secondary Voltages: 2 x 115V
- Current Rating: 3.47A
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 800VA
- Approval Bodies: DIN, EN, IEC, VDE
- External Depth: 200mm
- External Length / Height: 165mm
- External Width: 283mm
- Fixing Centres LxW: 245 x 148
- Height: 165mm
- Input Voltage: 230V
- Insulation Class: B
- Operating Temperature Max: 40°C
- Output Voltage: 115V
- Primary Voltages: 1 x 230V
- Protection Type: IP20
- Secondary No Load Voltage: 1.02V
- Secondary Power: 800VA
- Single Primary Voltage: 230V
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
- Test Voltage: 3750VAC
- Transformer Type: Isolation
- Type: Enclosed
- Weight: 15.6kg
