TMA 1215D Converter, DC/DC, 1W, +/-15V/0.04A TRACO Power

TRACO POWERUGS :TMA 1215D Code de commande:1007524

Prix:
Prix ​​promotionnel€8,18

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (313 unité)

Documents et téléchargements

description

TRACO POWER - TMA 1215D - Isolated Through Hole DC/DC Converter, ITE, 1:1, 1 W, 2 Output, 15 V, 35 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 1W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 35mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 35mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TMA Series
  • Input Voltage DC Min: 10.8V
  • Input Voltage DC Max: 13.2V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: SIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 6.1mm
  • Height: 10.2mm
  • Depth: 19.5mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency: 81%
  • External Depth: 6mm
  • Input Voltage: 12VDC
  • Isolation Voltage: 1kV
  • No. of Outputs: 2Outputs
  • Output Current - Max: 35mA
  • Output Voltage +: 15VDC
  • Output Voltage -: 15VDC
  • Power Rating: 1W
  • Supply Voltage: 12V
