TMH 0505D Converter, DC/DC, 2W, +/-5V/0.2A TRACO Power

TRACO POWERUGS :TMH 0505D Code de commande:1007554

Prix:
Prix ​​promotionnel€11,28

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (55 unité)

Documents et téléchargements

description

TRACO POWER - TMH 0505D - Isolated Through Hole DC/DC Converter, Ultraminiature, ITE, 1:1, 2 W, 2 Output, 5 V, 200 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 2W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 200mA
  • Output Voltage - Output 2: -5V
  • Output Current - Output 2: 200mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TMH Series
  • Input Voltage DC Min: 4.5V
  • Input Voltage DC Max: 5.5V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: SIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 7.5mm
  • Height: 10.2mm
  • Depth: 19.5mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency: 77%
  • Input Voltage: 5VDC
  • Isolation Voltage: 1kV
  • No. of Outputs: 2Outputs
  • Output Current - Max: 200mA
  • Output Ripple Voltage pk-pk: 75mV
  • Output Voltage +: 5VDC
  • Output Voltage -: 5VDC
  • Power Rating: 2W
  • Supply Voltage: 5V
