TRACO POWER - TMP 30112 - AC/DC PCB Mount Power Supply (PSU), ITE, 1 Output, 30 W, 12 V, 2.5 A
- No. of Outputs: 1 Output
- Output Power Max: 30W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 2.5A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Fixed
- Input Voltage VAC: 85V AC to 264V AC
- Width: 63.5mm
- Height: 21.5mm
- Depth: 88.9mm
- Product Range: TMP Series
- SVHC: No SVHC (27-Jun-2018)
- Applications: General Purpose
- Approval Bodies: CB, EN, IEC, UL
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 85V
- Length: 88.9mm
- No. of Outputs: 1Outputs
- Output Current Max: 2.5A
- Power Rating: 30W
- Power Supply Type: Enclosed
- Supply Voltage Typ: 115V AC, 230V AC
