TMP 30512 Converter, AC/DC, 5V&±12V/30W, Module TRACO Power

TRACO POWERUGS :TMP 30512 Code de commande:1672157

Prix:
Prix ​​promotionnel€98,00

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (5 unité)

Documents et téléchargements

description

TRACO POWER - TMP 30512 - AC/DC PCB Mount Power Supply (PSU), ITE, 3 Output, 30 W, 5 V, 3 A, 12 V

  • No. of Outputs: 3 Output
  • Output Power Max: 30W
  • Output Voltage - Output 1: 5V
  • Output Current - Output 1: 3A
  • Output Voltage - Output 2: 12V
  • Output Current - Output 2: 600mA
  • Output Voltage - Output 3: -12V
  • Output Current - Output 3: 600mA
  • Power Supply Output Type: Fixed
  • Input Voltage VAC: 85V AC to 264V AC
  • Width: 63.5mm
  • Height: 21.5mm
  • Depth: 88.9mm
  • Product Range: TMP Series
  • SVHC: No SVHC (27-Jun-2018)
  • Applications: General Purpose
  • Approval Bodies: CB, EN, IEC, UL
  • Input Voltage AC Max: 264V
  • Input Voltage AC Min: 85V
  • Length: 88.9mm
  • No. of Outputs: 3Outputs
  • Power Rating: 30W
  • Power Supply Type: Enclosed
  • Supply Voltage Typ: 115V AC, 230V AC
