TMR 3-0523 Converter, DC/DC, 3W, +/-15V/0.1A TRACO Power

TRACO POWERUGS :TMR 3-0523 Code de commande:1284234

Prix:
Prix ​​promotionnel€33,46

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (21 unité)

Documents et téléchargements

description

TRACO POWER - TMR 3-0523 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 3 W, 2 Output, 15 V, 100 mA

  • No. of Outputs: 2 Output
  • Output Power Max: 3W
  • Output Voltage - Output 1: 15V
  • Output Current - Output 1: 100mA
  • Output Voltage - Output 2: -15V
  • Output Current - Output 2: 100mA
  • Output Voltage - Output 3: -
  • Output Current - Output 3: -
  • Product Range: TMR 3 Series
  • Input Voltage DC Min: 4.5V
  • Input Voltage DC Max: 9V
  • DC / DC Converter Output Type: Fixed
  • DC / DC Converter Type: SIP
  • DC / DC Converter Mounting: Through Hole
  • Width: 9.2mm
  • Height: 11.1mm
  • Depth: 21.8mm
  • SVHC: No SVHC (27-Jun-2018)
  • Efficiency: 80%
  • Isolation Voltage: 1.5kV
  • Load Regulation: 1%
  • No. of Outputs: 2Outputs
  • Output Current - Max: -100mA
  • Output Voltage +: +15VDC
  • Output Voltage -: -15VDC
  • Power Rating: 3W
  • Supply Voltage: 5V
