TRACO POWER - TOP 200-112 - AC/DC Open Frame Power Supply (PSU), ITE, 1 Output, 200 W, 85V AC to 264V AC, Fixed
- No. of Outputs: 1 Output
- Power Rating (Covection Cooling): 200W
- Power Rating (Forced Cooling): -
- Input Voltage VAC: 85V AC to 264V AC
- Power Supply Output Type: Fixed
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 16A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Output Voltage - Output 4: -
- Current, Output 4: -
- Product Range: TOP 200 Series
- SVHC: No SVHC (27-Jun-2018)
- Applications: Industrial
- Height: 34mm
- Input Frequency: 63Hz
- Input Voltage: 85V AC to 264V AC
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 85V
- Length: 127mm
- No. of Outputs: 1Outputs
- Operating Temperature Max: 70°C
- Operating Temperature Min: -25°C
- Output Current Max: 16A
- Output Power Max: 200W
- Output Ripple Voltage pk-pk: 120mV
- Power Rating: 200W
- Power Supply Type: Open Frame
- Supply Voltage Typ: 120V AC, 240V AC
- Width: 76.2mm
