PANASONIC - TQ2-12V - Signal Relay, 12 VDC, DPDT, 1 A, TQ, Through Hole, Non Latching
- Coil Voltage: 12VDC
- Contact Configuration: DPDT
- Contact Current: 1A
- Product Range: TQ Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Relay Terminals: Solder
- Contact Voltage VAC: -
- Contact Voltage VDC: 30V
- Contact Material: Gold
- Coil Resistance: 1.028kohm
- SVHC: No SVHC (07-Jul-2017)
- Approvals & Standards: CSA, UL
- Coil Current: 11.7mA
- Coil Operating Lower Percent Limit: 75%
- Coil Operating Upper Percent Limit: 130%
- Coil Power Continuous: 140mW
- Coil Voltage VDC Nom: 12V
- Contact Current AC Max: 0.5A
- Contact Current DC Max: 0.1A
- Contact Current Max: 1A
- Contact Current Min: 10µA
- Contact Voltage AC Nom: 125V
- Contact Voltage DC Nom: 30V
- External Depth: 4.75mm
- External Height: 14mm
- External Width: 9mm
- Lead Spacing: 2.54mm
- Operating Temperature Max: 70°C
- Operating Temperature Min: -40°C
- Operating Time: 4ms
- Relay Type: General Purpose
- Release Time: 4ms
