ULR25-R004FT2 CURRENT SENSE RES, 0R004, 1%, 2.5 W TT ELECTRONICS / WELWYN

TT ELECTRONICS / WELWYNUGS :ULR25-R004FT2 Code de commande:1292498

Prix:
Prix ​​promotionnel€2,57

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (7490 unité)

Documents et téléchargements

description

TT ELECTRONICS / WELWYN - ULR25-R004FT2 - SMD Current Sense Resistor, 0.004 ohm, ULR, 2512 [6432 Metric], 2.5 W, ± 1%, Metal Strip

  • Resistance: 0.004ohm
  • Product Range: ULR Series
  • Resistor Case Style: 2512 [6432 Metric]
  • Power Rating: 2.5W
  • Resistance Tolerance: ± 1%
  • Resistor Element Material: Metal Strip
  • Temperature Coefficient: ± 50ppm/°C
  • Automotive Qualification Standard: AEC-Q200
  • SVHC: No SVHC (15-Jan-2019)
  • External Depth: 0.6mm
  • External Length / Height: 6.35mm
  • External Width: 3.18mm
  • No. of Pins: 2Pins
  • Operating Temperature Max: 170°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Range: -55°C to +170°C
  • Resistor Mounting: Surface Mount Device
  • Temperature Coeff. +: 50ppm/°C
  • Temperature Coeff. -: 50ppm/°C
  • Tolerance +: 1%
  • Tolerance -: 1%
  • Voltage Rating: 200V
  • Voltage Rating V DC: 200V
