description
NICHICON - UPS1J102MHD - Electrolytic Capacitor, Miniature, 1000 µF, 63 V, ± 20%, Radial Leaded, 3000 hours @ 105°C, Polar
- Capacitance: 1000µF
- Voltage Rating: 63V
- Product Range: PS Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 16mm
- Lead Spacing: 7.5mm
- Height: 31.5mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 3000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 31.5mm
- Impedance: 0.049ohm
- Lead Diameter: 0.8mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +105°C
- Operating life Time: 3000h
- Ripple Current AC: 1380mA
- Ripple Current Frequency: 120Hz
- Ripple Current Temperature: 105°C
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 63V
