SCHRACK - TE CONNECTIVITY - 5-1393236-7 - General Purpose Relay, SNR Series, Non Latching, SPDT, 5 VDC, 6 A
- Contact Configuration: SPDT
- Coil Voltage: 5VDC
- Contact Current: 6A
- Product Range: SNR Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Tin Oxide
- Coil Resistance: 148ohm
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: VDE
- Approval Category: UL Recognised
- Coil Operating Lower Percent Limit: 65%
- Coil Operating Upper Percent Limit: 160%
- Coil Sensitivity: 170mW
- Coil Voltage VDC Nom: 5V
- Contact Current AC Max: 6A
- Contact Current Max: 6A
- Contact Voltage AC Max: 250V
- Contact Voltage AC Nom: 240V
- Contact Voltage DC Max: 300V
- DC Coil Power: 170mW
- Dielectric Strength VDC: 4kV
- Dielectric Voltage Coil to Contact: 4kV
- Dielectric Voltage Contact to Contact: 1kV
- External Depth: 15mm
- External Height: 28mm
- External Length / Height: 28mm
- External Width: 5mm
- Must Actuate Voltage: 3.5V
- Must Release Voltage: 0.25V
- Nom Operating Power: 170mW
- Operating Temperature Max: 85°C
- Weight: 6g
