BLOCK - VB 0.35/1/9 - PCB Transformer, Class II, Encapsulated Safety Isolating, 230V, 9V, 350 mVA, 50Hz / 60Hz
- Power Rating: 350mVA
- Secondary Voltages: 9V
- Current Rating: 39mA
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- External Depth: 15mm
- External Length / Height: 22mm
- External Width: 22.7mm
- Hole Spacing - Length: 15mm
- Pin Diameter: 0.6mm
- Pin Length: 5mm
- Pitch Spacing: 15mm
- Primary Voltages: 1 x 230V
- Supply Frequency Max: 60Hz
- Supply Frequency Min: 50Hz
