BLOCK - VB0.5/2/15 - PCB Transformer, EE 20 x 10.5, Encapsulated Safety Isolating, 230V, 2 x 15V, 500 mVA, 50Hz / 60Hz
- Power Rating: 500mVA
- Secondary Voltages: 2 x 15V
- Current Rating: 16mA
- Isolation Transformer Primary Voltages: 1 x 230V
- Plug Type: -
- Product Range: -
- SVHC: No SVHC (12-Jan-2017)
- AC Power: 0.5VA
- Approval Bodies: CSA, UL, VDE
- External Depth: 19mm
- External Length / Height: 22.7mm
- External Width: 22mm
- Flammability Rating: UL94V-0
- Hole Spacing - Length: 15mm
- Input Voltage: 230V
- Isolation Voltage: 5kV
- Lead Spacing: 5mm
- Output 2 Voltage Max: 15V
- Output Voltage: 15V
- Pin Diameter: 0.6mm
- Pin Length: 5mm
- Pitch Spacing: 15mm
- Primary Voltages: 1 x 230V
- Regulation: 40%
- Secondary Power: 0.25VA
- Single Primary Voltage: 230V
- Transformer Type: Encapsulated
- Weight: 35g
