KYOCERA AVX - VC08LC18A500RP - TVS Varistor, 14 V, 18 V, StaticGuard, 50 V, 0805 [2012 Metric], Multilayer Varistor (MLV)
- Voltage Rating VAC: 14V
- Voltage Rating V DC: 18V
- Product Range: StaticGuard Series
- Clamping Voltage Vc Max: 50V
- Varistor Case Style: 0805 [2012 Metric]
- Varistor Type: Multilayer Varistor (MLV)
- Peak Surge Current @ 8/20µs: 30A
- Operating Temperature Min: -
- Operating Temperature Max: -
- Peak Energy (10/1000uS): 10mJ
- Automotive Qualification Standard: -
- SVHC: No SVHC (17-Dec-2015)
- Capacitance: 80pF
- Clamping Voltage: 50V
- Clamping Voltage @ 8/20µs Max: 50VDC
- Peak Pulse Current IPP @ 8/20µs: 30A
- Suppressor Type: Transient Voltage
- Surge Current: 30A
