XP POWER - VCP15US05 - AC/DC PCB Mount Power Supply (PSU), ITE & Medical, 1 Output, 10 W, 5 V, 2 A
- No. of Outputs: 1 Output
- Output Power Max: 10W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 2A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Power Supply Output Type: Fixed
- Input Voltage VAC: 90V AC to 264V AC
- Width: 38mm
- Height: 21.5mm
- Depth: 65mm
- Product Range: VCP Series
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: cUL, EN, IEC
- Approvals / Standards: EN 60601, IEC 60601, UL 60601
- Efficiency: 73%
- External Depth: 38mm
- External Length / Height: 31.4mm
- External Width: 65mm
- Input Voltage: 90V AC to 264V AC
- Input Voltage AC Max: 264V
- Input Voltage AC Min: 90V
- Length: 38mm
- No. of Outputs: 1Outputs
- Operating Temperature Max: 50°C
- Operating Temperature Min: 0°C
- Output Current Max: 2A
- Output Ripple Voltage pk-pk: 100mV
- Power Rating: 10W
- Power Supply Type: Switch Mode
- Supply Voltage Max: 264V
- Supply Voltage Min: 90V
- Supply Voltage Typ: 110V AC, 230V AC
