VS-25RIA80 Thyristor, 25A, 800V, TO-48 Vishay

VISHAYUGS :VS-25RIA80 Code de commande:9104607

Prix:
Prix ​​promotionnel€26,26

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
En stock (132 unité)

Documents et téléchargements

description

VISHAY - VS-25RIA80 - Thyristor Module, 25 A, 800 V

  • SCR Module Type: Single SCR
  • Peak Repetitive Off-State Voltage, Vdrm: 800V
  • Gate Trigger Current Max, Igt: 60mA
  • Current It av: 25A
  • On State RMS Current IT(rms): 40A
  • Peak Non Rep Surge Current Itsm 50Hz: 420A
  • Holding Current Max Ih: 130mA
  • Gate Trigger Voltage Max Vgt: 2V
  • Operating Temperature Max: 125°C
  • Product Range: -
  • Current Itsm: 350A
  • No. of Pins: 3Pins
  • Operating Temperature Min: -65°C
  • Operating Temperature Range: -65°C to +125°C
  • Repetitive Reverse Voltage Vrrm Max: 800V
  • Termination Type: Screw
  • Thread Size: 10-32UNF
  • Thyristor Case: TO-208AA
  • Thyristor Case Style: TO-208AA
  • Thyristor Type: Thyristor
