XP POWER - WD201 - Isolated Through Hole DC/DC Converter, Input Pi Filter, ITE, 2:1, 15 W, 1 Output, 5 V, 3 A
- No. of Outputs: 1 Output
- Output Power Max: 15W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 3A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 25.4mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 50.8mm
- External Length / Height: 10.2mm
- External Width: 25.4mm
- Isolation Voltage: 500V
- No. of Outputs: 1Outputs
- Operating Temperature Max: 71°C
- Operating Temperature Min: -25°C
- Power Rating: 15W
- Supply Voltage: 24V
