WS.005.3116 (80.010.4100.0) Relay, SPDT, 250VAC, 300VDC, 6a Wieland Electric

WIELAND ELECTRICUGS :WS.005.3116 (80.010.4100.0) Code de commande:1212086

Prix:
Prix ​​promotionnel€37,24

incl. T.V.A. Calcul des frais d'expédition à la caisse

Stock:
Seulement 3 produits disponibles

Documents et téléchargements

description

WIELAND ELECTRIC - WS.005.3116 (80.010.4100.0) - General Purpose Relay, Flare Series, Interface, SPDT, 24 VDC, 6 A

  • Contact Configuration: SPDT
  • Coil Voltage: 24VDC
  • Contact Current: 6A
  • Product Range: Flare Series
  • Relay Mounting: DIN Rail
  • Coil Type: -
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Spring Clamp
  • Contact Voltage VDC: 300VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: -
  • SVHC: No SVHC (12-Jan-2017)
  • Approval Bodies: EN, VDE
  • Average Power Consumption: 350mW
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 6A
  • Contact Current DC Max: 2A
  • Contact Current Max: 6A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Max: 300V
  • Current Rating: 10A
  • External Depth: 70mm
  • External Length / Height: 89mm
  • External Width: 6.2mm
  • Relay Type: Interface
  • Switch Current Max: 6A
  • Switched Current Max: 6A
  • Switching Current Max: 6A
