0154.250DR Fuse, SMD, Omni Block, F 250mA LITTELFUSE

LITTELFUSESKU:0154.250DR Bestelcode:9943617

Prijs:
Actie prijs€6,37

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (977 units)

Documenten en downloads

Omschrijving

LITTELFUSE - 0154.250DR - Fuse, Surface Mount with Clip/Holder, 250 mA, Very Fast Acting, 125 VAC, 125 VDC, 9.73mm x 5.03mm

  • Fuse Current: 250mA
  • Product Range: OMNI-BLOK Series
  • Voltage Rating VAC: 125VAC
  • Voltage Rating V DC: 125VDC
  • Blow Characteristic: Very Fast Acting
  • Fuse Case Style: SMD
  • Breaking Capacity Current AC: 50A
  • Breaking Capacity Current DC: -
  • Approval Bodies: CSA, UL
  • Current Rating: 7A
  • External Depth: 9.73mm
  • External Height: 3.81mm
  • External Length / Height: 0.418"
  • External Width: 5.03mm
  • Flammability Rating: UL94V-0
  • Fuse Size Code: Nano²
  • Fuse Size Held: Nano²
  • Fuse Type Blowing Characteristic: Quick Blow
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -55°C
  • Overall Height: 3.81mm
  • Overall Length: 10.62mm
  • SMD Fuse Case Style: Nano²
