09 19 510 7323 Header, Right Angle, 10WAY Harting

HARTINGSKU:09 19 510 7323 Bestelcode:1106782

Prijs:
Actie prijs€3,80

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (42 units)

Documenten en downloads

Omschrijving

HARTING - 09 19 510 7323 - Pin Header, Right Angle, Wire-to-Board, 2.54 mm, 2 Rows, 10 Contacts, Through Hole Right Angle

  • Pitch Spacing: 2.54mm
  • No. of Contacts: 10Contacts
  • Gender: Header
  • Product Range: SEK 19 Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 2Rows
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Brass
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Bodies: BS, BT, DIN, F, MIL Spec, NFC
  • Colour: Grey
  • Contact Resistance: 20mohm
  • Current Rating: 1A
  • Cut Thickness for PCBs Max: 2.4mm
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 1Gohm
  • No. of Mating Cycles: 100
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • PCB Hole Diameter: 0.9mm
  • Voltage Rating V DC: 350V
  • Voltage Rating VAC: 350V
  • Withstand Voltage: 1050V
  • Working Voltage: 350V
