HARTING - 09 69 511 5247 - Combination Layout D Sub Connector, Mixed Signal, D Sub-M, DD-24W7, Plug, 24 Contacts
- Product Range: D Sub-M Series
- Insert Arrangement: DD-24W7
- No. of Signal Contacts: 17Contacts
- Gender: Plug
- No. of Power Positions: 7
- Contact Termination Type: Solder Cup
- D Sub Shell Size: DD
- Connector Body Material: Metal Body
- Contact Material: Copper Alloy
- Contact Plating: Gold Plated Contacts
- SVHC: No SVHC (15-Jan-2018)
- Connector Insert Type: 24W7
- Connector Mounting: Cable Mount
- Contact Termination: Solder
- Contact Type: 17 Signal, 7 Power
- Material: Tinned Metal
- No. of Contacts: 24Contacts
- No. of Mating Cycles: 500
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
