Omschrijving
MULTICOMP PRO - 100-26W - Wire, Solid, Wrapping, PVDF, White, 26 AWG, 0.128 mm², 328 ft, 100 m
- Jacket Material: PVDF
- Jacket Colour: White
- Wire Gauge: 26AWG
- Conductor Area CSA: 0.128mm²
- Reel Length (Imperial): 328ft
- Reel Length (Metric): 100m
- No. of Max Strands x Strand Size: Solid
- Voltage Rating: 300V
- Conductor Material: Tinned Copper
- External Diameter: 0.69mm
- Approval Specification: -
- Product Range: -
- SVHC: No SVHC (17-Dec-2015)
- Conductor Make-up: 1 / 0.4mm
- Conductor Plating: Silver
- Operating Temperature Max: 105°C
- Operating Temperature Min: -60°C
- Outer Diameter: 0.69mm
- Voltage Rating VAC: 300V
- Wire Size: 26AWG
