1119107 Cable, YY, 7CORE, 0.75mm, 50m Lapp Kabel

LAPP KABELSKU:1119107 Bestelcode:1204059

Prijs:
Actie prijs€97,33

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (21 units)

Documenten en downloads

Omschrijving

LAPP KABEL - 1119107 - Multicore Cable, Ölflex® YY, Unscreened, 7 Core, 19 AWG, 0.75 mm², 164 ft, 50 m

  • Cable Shielding: Unscreened
  • No. of Cores: 7Core
  • Wire Gauge: 19AWG
  • Conductor Area CSA: 0.75mm²
  • Reel Length (Imperial): 164ft
  • Reel Length (Metric): 50m
  • Jacket Colour: Grey
  • No. of Max Strands x Strand Size: -
  • Conductor Material: Copper
  • Jacket Material: PVC
  • External Diameter: 7.3mm
  • Voltage Rating: 500V
  • Product Range: YY Series
  • SVHC: No SVHC (15-Jan-2019)
  • Bend Radius Min: 15mm
  • Cable Type: Unshielded
  • Core-Earth / Core-Core Voltage Rating: 300/500 V
  • Flexing Temperature Max: 70°C
  • Flexing Temperature Min: -5°C
  • Installed Bend Radius Min: 4
  • Insulation Resistance: 20Gohm
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -5°C
  • Outer Diameter: 7.3mm
  • Secondary Insulation Colour: Grey
  • Secondary Insulation Material: PVC
  • Test Voltage: 4000V
  • Voltage Rating VAC: 500V
