1136303 100m Cable, Ctrl, CY, 3CORE, 1.5mm, 100m Lapp Kabel

LAPP KABELSKU:1136303 100M Bestelcode:1179083

Prijs:
Actie prijs€308,79

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Nog maar 3 producten leverbaar

Documenten en downloads

Omschrijving

LAPP KABEL - 1136303 100M - Multicore Cable, Ölflex® CY, Screened, 3 Core, 16 AWG, 1.5 mm², 328 ft, 100 m

  • Cable Shielding: Screened
  • No. of Cores: 3Core
  • Wire Gauge: 16AWG
  • Conductor Area CSA: 1.5mm²
  • Reel Length (Imperial): 328ft
  • Reel Length (Metric): 100m
  • Jacket Colour: Grey
  • No. of Max Strands x Strand Size: 30 x 0.25mm
  • Conductor Material: Copper
  • Jacket Material: PVC
  • External Diameter: 7.5mm
  • Voltage Rating: 500V
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2019)
  • Bend Radius Min: 20mm
  • Cable Type: CY
  • Conductor Make-up: 30 / 0.25mm
  • Core-Earth / Core-Core Voltage Rating: 300/500
  • Current Rating: 16A
  • Flexing Temperature Max: 70°C
  • Flexing Temperature Min: -5°C
  • Installed Bend Radius Min: 6
  • Insulation Resistance: 20Gohm
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -30°C
  • Outer Diameter: 7.5mm
  • Secondary Insulation Colour: Grey
  • Secondary Insulation Material: PVC
  • Shield Material: Tinned Copper
  • Shield Type: Tinned Copper Braid
  • Test Voltage: 4000V
