BELDEN - 1189A 0101000 - Coaxial Cable, Quad Shield CATV, RG6, 18 AWG, 75 ohm, 1000 ft, 304.8 m
- Coaxial Cable Type: RG6
- Wire Gauge: 18AWG
- Conductor Area CSA: -
- Impedance: 75ohm
- Reel Length (Imperial): 1000ft
- Reel Length (Metric): 304.8m
- Jacket Colour: Black
- Jacket Material: PVC
- Conductor Material: Copper Coated Steel
- No. of Max Strands x Strand Size: Solid
- External Diameter: 7.47mm
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Attenuation @ 1GHz: 6.54dB
- Attenuation @ 300MHz: 3.43dB
- Attenuation @ 400MHz: 4dB
- Attenuation @ 5MHz: 0.67dB
- Core-Screen Capacitance: 16.2pF/ft
- Operating Temperature Max: 80°C
- Operating Temperature Min: -40°C
- Velocity of Propagation (%): 83%
