1MS2T1B5M1QE Switch, Solder Tag, SPDT, On-Mom multicomp Pro

MULTICOMP PRO - 1MS2T1B5M1QE - Toggle Switch, On-(On), SPDT, Non Illuminated, 1M, Panel Mount, 5 A

• Switch Operation: On-(On)
• Contact Configuration: SPDT
• Illumination: Non Illuminated
• Product Range: 1M Series
• Contact Current Max: 5A
• Switch Mounting: Panel
• Contact Voltage AC Nom: 120V
• Switch Terminals: Solder
• Contact Voltage DC Nom: 28V
• SVHC: No SVHC (15-Jan-2018)
• Actuation Type: Bat
• Approval Category: UL Recognised
• Bush Thread Length: 8.89mm
• Contact Current AC: 2A
• Contact Current AC Max: 5A
• Contact Current DC Max: 5A
• Contact Resistance: 10mohm
• Contact Resistance Max: 100mohm
• Contact Voltage AC Max: 250VAC
• Contact Voltage DC Max: 28VDC
• External Depth: 6.86mm
• External Length / Height: 8.89mm
• External Width: 12.7mm
• Flammability Rating: UL94V-0
• Insulation Resistance: 1000Mohm
• Lever Length: 10.41mm
• Material: DAP
• No. of Mechanical Operations: 40000
• Operating Temperature Max: 85°C
• Operating Temperature Min: -30°C
• Switching Current AC Max: 5A
• Switching Current DC Max: 5A
• Tab Blade Thickness: 0.76mm
• Termination Method: Solder
• Thread Size: ¼ - 40 UNS-2A
