Omschrijving
RUBYCON - 200VXG1000MEFCSN30X35 - Electrolytic Capacitor, Miniaturized, 1000 µF, 200 V, ± 20%, Snap-In, 5000 hours @ 105°C
- Capacitance: 1000µF
- Voltage Rating: 200V
- Product Range: VXG Series
- Lifetime @ Temperature: 5000 hours @ 105°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 30mm
- Lead Spacing: 10mm
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- Height: 35mm
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- External Length / Height: 35mm
- Frequency Tolerance: 120Hz
- No. of Pins: 2Pins
- Operating Temperature Range: -25°C to +105°C
- Operating life Time: 5000h
- Ripple Current AC: 2.06A
- Ripple Current Frequency: 120Hz
- Ripple Current Temperature: 105°C
- Tolerance +: 20%
- Tolerance -: 20%
- Tolerance Temperature: 20°C
- Voltage Rating V DC: 200V
- Voltage Rating VAC: 200V
