205-532-21-38 LED, Mid Groove, 12V, Green Marl

MARLSKU:205-532-21-38 Bestelcode:9738517

Prijs:
Actie prijs€18,69

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Uitverkocht

Documenten en downloads

Omschrijving

MARL - 205-532-21-38 - LED Replacement Lamp, Midget Groove / S5.7s, Green, T-1 3/4 (5mm), 500 mW, 527 nm, 23 cd

  • Lamp Base Type: Midget Groove / S5.7s
  • LED Colour: Green
  • Bulb Size: T-1 3/4 (5mm)
  • Power Rating: 500mW
  • Wavelength Typ: 527nm
  • Luminous Intensity: 23cd
  • Average Bulb Life: 100000h
  • Supply Voltage: 12V
  • Current Rating: 20mA
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2019)
  • Angle of Half Sensitivity ±: 42.5°
  • Colour: Green
  • External Diameter: 5.6mm
  • Forward Current If Max: 20mA
  • Forward Current If(AV): 20mA
  • Forward Voltage: 12V
  • LED / Lamp Size: 4.8mm
  • LED Colour Presentation: Untinted Clear
  • Luminous Intensity Typ: 6000mcd
  • Operating Temperature Max: 50°C
  • Operating Temperature Min: -20°C
  • Operating Temperature Range: -20°C to +50°C
  • Peak Wavelength: 525nm
  • Viewing Angle: 85°
  • Voltage Rating V DC: 12V
