2212S-14SG-85 Socket, Pcb, 1 Row, 14WAY multicomp Pro

MULTICOMP PROSKU:2212S-14SG-85 Bestelcode:1593466

Prijs:
Actie prijs€1,02

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (2805 units)

Documenten en downloads

Omschrijving

MULTICOMP PRO - 2212S-14SG-85 - PCB Receptacle, Board-to-Board, 2.54 mm, 1 Rows, 14 Contacts, Through Hole Mount, 2212S

  • Pitch Spacing: 2.54mm
  • No. of Contacts: 14Contacts
  • Gender: Receptacle
  • Product Range: 2212S Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 1Rows
  • Contact Plating: Gold Plated Contacts
  • Contact Material: Phosphor Bronze
  • SVHC: No SVHC (15-Jan-2019)
  • Contact Resistance: 20mohm
  • Contact Termination: Solder
  • Current Rating: 3A
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 1000Mohm
  • Lead Spacing: 2.54mm
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • Termination Method: Solder
  • Voltage Rating VAC: 250V
  • Withstand Voltage: 600V
