Omschrijving
OPTO 22 - 240A25 - Solid State Relay, 25 A, 280 VAC, Panel Mount, Screw, Zero Crossing
- Contact Configuration: -
- Load Current: 25A
- Operating Voltage Max: 280VAC
- Relay Mounting: Panel
- Relay Terminals: Screw
- Switching Mode: Zero Crossing
- Operating Voltage Min: 24VAC
- Control Voltage Min: 85VAC
- Control Voltage Max: 280VAC
- Product Range: AC Series
- SVHC: No SVHC (27-Jun-2018)
- Control Voltage AC Max: 280VAC
- Control Voltage AC Min: 85VAC
- Control Voltage Range: 85V AC to 280V AC
- Control Voltage Type: AC
- I2t: 250s
- Isolation Voltage: 4kV
- Leakage Current: 14mA
- Load Current RMS Max: 25A
- Operating Current AC: 25A
- Operating Temperature Max: 100°C
- Operating Temperature Min: -40°C
- Operating Voltage Range: 24V AC to 280V AC
- Output Type: Thyristor
- RMS Load Voltage Max: 480V
- RMS Load Voltage Min: 24V
- Single Cycle Surge Current: 250A
