Omschrijving
PHOENIX CONTACT - 3205035 - DIN Rail Mount Terminal Block, 2 Ways, 24 AWG, 16 AWG, 1.5 mm², Screw
- No. of Positions: 2Ways
- Wire Size AWG Min: 24AWG
- Wire Size AWG Max: 16AWG
- Conductor Area CSA: 1.5mm²
- Wire Connection Method: Screw
- Rated Current: -
- Rated Voltage: -
- No. of Levels: 1
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- Colour: Yellow / Green
- Connector Mounting: DIN Rail Mount
- Connector Type: Terminal Block, DIN Rail
- External Depth: 39.5mm
- External Length / Height: 58.8mm
- External Width: 5.2mm
- Height: 58.8mm
- Pitch Spacing: 5.2mm
- Voltage Rating VAC: 400V
- Wire Area Size Max: 1.5mm²
- Wire Area Size Min: 0.25mm²
