SCHURTER - 3403.0175 - Fuse, Surface Mount, 8 A, Slow Blow, 250 VAC, 125 VDC, 4012, UMT 250
- Fuse Current: 8A
- Product Range: UMT 250 Series
- Voltage Rating VAC: 250VAC
- Voltage Rating V DC: 125VDC
- Blow Characteristic: Time Delay
- Fuse Case Style: SMD
- Breaking Capacity Current AC: 35A
- Breaking Capacity Current DC: 35A
- SVHC: No SVHC (15-Jan-2019)
- Approval Category: UL Recognised
- Breaking Capacity: 35A @ 250V AC / 125V DC, 200A @ 63V AC / DC
- Case Material: Ceramic
- External Depth: 3mm
- External Length / Height: 3mm
- External Width: 10.1mm
- Fuse Breaking Capacity Voltage AC: 250VAC
- Fuse Type Blowing Characteristic: Time Lag
- Operating Temperature Max: 125°C
- Operating Temperature Min: -55°C
- Standard: IEC 60127-4/2
