FINDER - 34.81.7.012.8240 - Solid State Relay, SPST-NO, 2 A, 17 VDC, PCB, Screw
- Contact Configuration: SPST-NO
- Load Current: 2A
- Operating Voltage Max: 17VDC
- Relay Mounting: PCB
- Relay Terminals: Screw
- Switching Mode: -
- Operating Voltage Min: 8VDC
- Control Voltage Min: -
- Control Voltage Max: -
- Product Range: 34 Series
- SVHC: No SVHC (15-Jan-2019)
- Coil Resistance: 1.94kohm
- Coil Voltage: 12VDC
- Coil Voltage VDC Nom: 12V
- Contact Current: 2mA
- Contact Current Max: 2mA
- Contact Material: Silver Nickel
- Contact Voltage AC Nom: 240V
- Contact Voltage DC Nom: 24V
- Contact Voltage VDC: 24V
- Control Voltage Type: DC
- External Depth: 5mm
- External Height: 15mm
- External Width: 28mm
- Load Voltage Range: 12V AC to 240V AC
- Nom Operating Power: 87mW
