AMP - TE CONNECTIVITY - 350434-1 - Pin Header, Wire-to-Board, 6.35 mm, 5 Rows, 15 Contacts, Through Hole Straight
- Pitch Spacing: 6.35mm
- No. of Contacts: 15Contacts
- Gender: Header
- Product Range: Universal MATE-N-LOK Series
- Contact Termination Type: Through Hole
- No. of Rows: 5Rows
- Contact Plating: Tin Plated Contacts
- Contact Material: Phosphor Bronze
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: CSA, UL, VDE
- Colour: Clear
- Contact Resistance: 3.5mohm
- Current Rating: 12A
- Flammability Rating: UL94V-2
- Insulation Resistance: 1000Mohm
- Material: Nylon
- No. of Mating Cycles: 50
- Operating Temperature Max: 105°C
- Operating Temperature Min: -55°C
- PCB Hole Diameter: 1.8mm
- Voltage Rating VAC: 600V
- Working Voltage: 600V
