35362-0250 Connector, Header, 2Pos, 1ROW, 2mm Molex

MOLEXSKU:35362-0250 Bestelcode:9289356

Prijs:
Actie prijs€0,62

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (43790 units)

Omschrijving

MOLEX - 35362-0250 - Pin Header, Straight, Wire-to-Board, 2 mm, 1 Rows, 2 Contacts, Through Hole Straight

  • Pitch Spacing: 2mm
  • No. of Contacts: 2Contacts
  • Gender: Header
  • Product Range: Sherlock 35362 Series
  • Contact Termination Type: Through Hole
  • No. of Rows: 1Rows
  • Contact Plating: Tin Plated Contacts
  • Contact Material: Brass
  • SVHC: No SVHC (15-Jan-2019)
  • Contact Resistance Max: 20mohm
  • Current Max: 2A
  • Current Rating: 2A
  • External Depth: 6mm
  • External Length / Height: 2.2mm
  • External Width: 8.3mm
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 1000Mohm
  • No. of Positions: 2Ways
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -40°C
  • Voltage Rating V DC: 125V
  • Voltage Rating VAC: 125V
  • Withstand Voltage: 500VAC
