35RX30100M8X11.5 Cap, 100µF, 35V, 20% RUBYCON

RUBYCONSKU:35RX30100M8X11.5 Bestelcode:8126585

Prijs:
Actie prijs€0,50

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (1910 units)

Documenten en downloads

Omschrijving

RUBYCON - 35RX30100M8X11.5 - Electrolytic Capacitor, Miniature, 100 µF, 35 V, ± 20%, Radial Leaded, 2000 hours @ 130°C, Polar

  • Capacitance: 100µF
  • Voltage Rating: 35V
  • Product Range: RX30 Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 8mm
  • Lead Spacing: 3.5mm
  • Height: 11.5mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 130°C
  • Lifetime @ Temperature: 2000 hours @ 130°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 11.5mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +130°C
  • Operating life Time: 4000h
  • Ripple Current AC: 360mA
  • Ripple Current Temperature: 105°C
  • Tolerance -: 20%
  • Voltage Rating V DC: 35V
