Omschrijving
TT ELECTRONICS / BI TECHNOLOGIES - 35WR100KLFTR - Trimpot, Single Turn, Cermet, Top Adjust, 100 kohm, Surface Mount, 1 Turns
- Track Resistance: 100kohm
- No. of Turns: 1Turns
- Potentiometer Mounting: Surface Mount Device
- Product Range: 35 Series
- Power Rating: 10mW
- Resistance Tolerance: ± 25%
- Temperature Coefficient: ± 250ppm/°C
- Automotive Qualification Standard: -
- MSL: -
- SVHC: No SVHC (20-Jun-2016)
- Adjustment Type: Screwdriver Slot
- External Depth: 3mm
- External Length / Height: 3.5mm
- External Width: 1.55mm
- Insulation Resistance: 100Mohm
- Operating Temperature Max: 125°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +125°C
- Resistor Element Material: Cermet
- Track Taper: Linear
- Voltage Rating: 50V
