37202000001 Fuse, ANTISURGE, TR5, 200mA LITTELFUSE

LITTELFUSESKU:37202000001 Bestelcode:1596444

Prijs:
Actie prijs€1,62

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (279 units)

Documenten en downloads

Omschrijving

LITTELFUSE - 37202000001 - Fuse, PCB Leaded, 200 mA, 250 VAC, TR5, Time Delay, Radial Leaded

  • Fuse Current: 200mA
  • Voltage Rating VAC: 250VAC
  • Product Range: TR5 Series
  • Voltage Rating V DC: -
  • Blow Characteristic: Time Delay
  • Fuse Case Style: Radial Leaded
  • Breaking Capacity Current AC: 35A
  • Breaking Capacity Current DC: -
  • Approval Bodies: CCC, METI, SEMKO, VDE
  • Approval Category: UL Recognised
  • Body Diameter: 8.5mm
  • Breaking Capacity: 35A @ 250V AC
  • Case Material: Thermoplastic Polyamide PA 6.6
  • External Length / Height: 8mm
  • Flammability Rating: UL 94 VO
  • Fuse Breaking Capacity Voltage AC: 250VAC
  • Fuse Mounting: Through Hole
  • Fuse Size Code: TR5
  • Fuse Size Imperial: 0.33" x 0.3"
  • Fuse Size Metric: 8.5mm x 8mm
  • Fuse Type Blowing Characteristic: Antisurge T
  • Lead Diameter: 0.6mm
  • Lead Length: 18.8mm
  • Lead Spacing: 5.08mm
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
