Omschrijving
3M - 3770/10 - Ribbon Cable, Round Conductor Flat, Unscreened, 10 Core, 26 AWG, 100 ft, 30.5 m
- Cable Shielding: Unscreened
- No. of Cores: 10Core
- Wire Gauge: 26AWG
- Conductor Area CSA: -
- Reel Length (Imperial): 100ft
- Reel Length (Metric): 30.5m
- Jacket Colour: Grey
- Cable Width: 12.7mm
- No. of Max Strands x Strand Size: 7 x 34AWG
- Pitch Spacing: 1.27mm
- Voltage Rating: 50V
- Conductor Material: Tinned Copper
- Jacket Material: TPE
- Ribbon Cable Type: Flat Ribbon Cable
- Product Range: 3770 Series
- Capacitance: 13.1pF/ft
- Impedance: 104ohm
- Inductance: 0.14µH
- Operating Temperature Max: 105°C
- Operating Temperature Min: -40°C
- Propagation Delay: 1.36ns/ft
