38.61.7.024.0050 Relay, SPDT, 250VAC, 6a Finder

FINDERSKU:38.61.7.024.0050 Bestelcode:1169351

Prijs:
Actie prijs€30,03

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (41 units)

Documenten en downloads

Omschrijving

FINDER - 38.61.7.024.0050 - General Purpose Relay, 38 Series, Interface, SPDT, 24 VDC, 6 A

  • Contact Configuration: SPDT
  • Coil Voltage: 24VDC
  • Contact Current: 6A
  • Product Range: 38 Series
  • Relay Mounting: DIN Rail
  • Coil Type: DC Sensitive
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Cage Clamp
  • Contact Voltage VDC: 30V
  • Contact Material: Silver Nickel
  • Coil Resistance: -
  • SVHC: No SVHC (15-Jan-2019)
  • Approval Bodies: BEAB, CSA, DEMKO, IMQ, SEMKO, SETI, SEV, UL, VDE
  • Approvals & Standards: CE, CSA, UL
  • Average Power Consumption: 300mVA
  • Coil Voltage VDC Nom: 24V
  • Contact Current AC Max: 6A
  • Contact Current Max: 10A
  • Contact Voltage AC Max: 250V
  • Contact Voltage AC Nom: 250V
  • Current Rating: 6A
  • Dielectric Strength VDC: 1000VAC
  • External Depth: 75.6mm
  • External Height: 93.6mm
  • External Length / Height: 93mm
  • External Width: 6.2mm
  • IP / NEMA Rating: IP20
  • Mechanical Life: 10,000,000 Operations
  • No. of Mechanical Operations: 10000000
  • Operating Temperature Max: 70°C
  • Operating Temperature Min: -40°C
  • Operating Time: 7ms
  • Relay Type: Interface
  • Release Time: 11ms
  • Switch Current Max: 10A
