40.52.8.240.0000 Relay, DPDT, 240Vac, 8A Finder

FINDERSKU:40.52.8.240.0000 Bestelcode:1169171

Prijs:
Actie prijs€15,10

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (282 units)

Documenten en downloads

Omschrijving

FINDER - 40.52.8.240.0000 - General Purpose Relay, 40 Series, Power, DPDT, 240 VAC, 8 A

  • Contact Configuration: DPDT
  • Coil Voltage: 240VAC
  • Contact Current: 8A
  • Product Range: 40 Series
  • Relay Mounting: Through Hole
  • Coil Type: AC
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30V
  • Contact Material: Silver Nickel
  • Coil Resistance: 31.5kohm
  • SVHC: No SVHC (15-Jan-2019)
  • Approvals & Standards: CSA, UL, VDE
  • Coil Current: 4.1mA
  • Coil Voltage VAC Nom: 240V
  • Contact Current Max: 15A
  • Contact Voltage AC Nom: 230V
  • Current Rating: 8A
  • External Depth: 25mm
  • External Height: 29mm
  • External Width: 12.4mm
  • Nom Operating Power: 1.2VA
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Relay Type: Power - General Purpose
