41.52.9.012.0010 Relay, DPDT, 250VAC, 8A Finder

FINDERSKU:41.52.9.012.0010 Bestelcode:1169311

Prijs:
Actie prijs€11,72

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (64 units)

Documenten en downloads

Omschrijving

FINDER - 41.52.9.012.0010 - General Purpose Relay, 41 Series, Power, DPDT, 12 VDC, 8 A

  • Contact Configuration: DPDT
  • Coil Voltage: 12VDC
  • Contact Current: 8A
  • Product Range: 41 Series
  • Relay Mounting: Through Hole
  • Coil Type: DC
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30V
  • Contact Material: Silver Nickel
  • Coil Resistance: 360ohm
  • SVHC: No SVHC (15-Jan-2019)
  • Coil Current: 33.3mA
  • Coil Voltage VDC Nom: 12V
  • Contact Current Max: 15mA
  • Contact Voltage AC Nom: 250V
  • Current Rating: 8A
  • External Depth: 12.6mm
  • External Height: 15.7mm
  • External Width: 29mm
  • Nom Operating Power: 400mW
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Operating Time: 5ms
  • Relay Type: Power - General Purpose
  • Release Time: 4ms
