4.16.26.09.64 CAP, 8µF, 450VAC, 5%, PP, CAN, PANEL DUCATI

DUCATISKU:4.16.26.09.64 Bestelcode:1219064

Prijs:
Actie prijs€13,53

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (5 units)

Documenten en downloads

Omschrijving

DUCATI - 4.16.26.09.64 - Motor Run Capacitor, Metallized PP, Can, 8 µF, ± 5%, Stud Mount - M8, 450 V

  • Capacitance: 8µF
  • Product Range: 4.16.26 Series
  • Voltage Rating: 450VAC
  • Capacitor Terminals: Quick Connect, Snap-In
  • Capacitance Tolerance: ± 5%
  • dv/dt Rating: -
  • Capacitor Dielectric Type: PP (Polypropylene)
  • Capacitor Case Style: Can
  • Height: 72mm
  • Diameter: 40mm
  • Stud Size - Metric: -
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (07-Jul-2017)
  • Body Diameter: 40mm
  • Capacitance Tolerance ±: ± 5%
  • Capacitor Application: Motor Start / Motor Run
  • Capacitor Mounting: Panel
  • Dissipation Factor: 0.002%
  • Dissipation Factor Temperature: 20°C
  • External Length / Height: 72mm
  • Lead Length: 6.35mm
  • Lead Spacing: 12mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -25°C to +85°C
  • Thread Size: M8x12
  • Tolerance +: 5%
  • Tolerance -: 5%
  • Voltage Rating VAC: 450V
