450VXG220MEFCSN30X30 Cap, 220µF, 450V, Alu Elec, Snap In RUBYCON

RUBYCONSKU:450VXG220MEFCSN30X30 Bestelcode:1281833

Prijs:
Actie prijs€11,05

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (11 units)

Documenten en downloads

Omschrijving

RUBYCON - 450VXG220MEFCSN30X30 - Electrolytic Capacitor, Snap-in, 220 µF, 450 V, ± 20%, Snap-In, 5000 hours @ 105°C

  • Capacitance: 220µF
  • Voltage Rating: 450V
  • Product Range: VXG Series
  • Lifetime @ Temperature: 5000 hours @ 105°C
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Quick Connect, Snap-In
  • Diameter: 30mm
  • Lead Spacing: 10mm
  • Operating Temperature Min: -25°C
  • Operating Temperature Max: 105°C
  • Height: 30mm
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Capacitance Tolerance ±: ± 20%
  • External Length / Height: 30mm
  • Frequency Tolerance: 120Hz
  • No. of Pins: 2Pins
  • Operating Temperature Range: -25°C to +105°C
  • Operating life Time: 5000h
  • Ripple Current AC: 1.1A
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 105°C
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Tolerance Temperature: 20°C
  • Voltage Rating V DC: 450V
  • Voltage Rating VAC: 450V
