MARL - 531-532-63 - LED Panel Mount Indicator, Weatherproof, Green, 28 V, 12.7 mm, 16 mA, 23 cd, IP67
- LED Colour: Green
- Operating Voltage: 28V
- Mounting Hole Dia: 12.7mm
- Forward Current If: 16mA
- Luminous Intensity: 23cd
- IP / NEMA Rating: IP67
- Product Range: 12.7mm Panel Mount LED 531 Series
- SVHC: No SVHC (15-Jan-2019)
- Behind Panel Depth: 29mm
- Bezel Depth: 3mm
- Bezel Diameter: 17mm
- Body Plating: Nickel
- Current If Min: 8mA
- Fixing Hole Diameter: 13mm
- Forward Current If Max: 16mA
- Forward Voltage: 28V
- Lead Length: 5mm
- Lens Colour: Colour Diffused
- Lens Shape: Round with Flat Top
- Luminous Intensity @ If = 20mA: 23000mcd
- Luminous Intensity Typ: 23000mcd
- Material: Brass
- Operating Temperature Max: 95°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +95°C
- Panel Cutout Diameter: 12.7mm
- Peak Forward Current: 20mA
- Reverse Protection Voltage: 1000VDC
- Storage Temperature Max: 100°C
- Storage Temperature Min: -40°C
- Supply Voltage Min: 12VDC
- Supply Voltage V DC: 28VDC
- Wavelength Typ: 527nm
