538-501-63 LED Indicator, 12-28V AC/DC, Red Marl

MARLSKU:538-501-63 Bestelcode:1498568

Prijs:
Actie prijs€48,53

Incl. BTW Verzendkosten berekening in de checkout

Voorraad:
Op voorraad (60 units)

Documenten en downloads

Omschrijving

MARL - 538-501-63 - LED Panel Mount Indicator, Weatherproof, Red, 28 VDC, 12.7 mm, 16 mA, 11 cd, IP67

  • LED Colour: Red
  • Operating Voltage: 28VDC
  • Mounting Hole Dia: 12.7mm
  • Forward Current If: 16mA
  • Luminous Intensity: 11cd
  • IP / NEMA Rating: IP67
  • Product Range: 12.7mm Panel Mount LED 538 Series
  • SVHC: No SVHC (15-Jan-2019)
  • Behind Panel Depth: 29mm
  • Bezel Diameter: 17mm
  • Current If Min: 8mA
  • Fixing Hole Diameter: 13mm
  • Forward Current If Max: 16mA
  • Forward Voltage: 28V
  • Lead Length: 5mm
  • Lens Colour: Colour Diffused
  • Luminous Intensity @ If = 20mA: 11000mcd
  • Luminous Intensity Typ: 11000mcd
  • Material: Stainless Steel
  • Operating Temperature Max: 95°C
  • Operating Temperature Min: -40°C
  • Operating Temperature Range: -40°C to +95°C
  • Panel Cutout Diameter: 13mm
  • Peak Forward Current: 20mA
  • Reverse Protection Voltage: 1000VDC
  • Storage Temperature Max: 100°C
  • Storage Temperature Min: -40°C
  • Supply Voltage Max: 28VDC
  • Supply Voltage Min: 12VDC
  • Wavelength Typ: 643nm
