VISHAY - 564R30GAQ27 - Ceramic Disc Capacitor, 27 pF, 3 kV, ± 20%, R3L, 6.4 mm, Radial Leaded
- Capacitance: 27pF
- Voltage Rating: 3kV
- Product Range: 564R Series
- Capacitance Tolerance: ± 20%
- Dielectric Characteristic: R3L
- Lead Spacing: 6.4mm
- Capacitor Terminals: Radial Leaded
- Operating Temperature Min: -25°C
- Operating Temperature Max: 105°C
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 8.4mm
- Capacitance Tolerance ±: ± 20%
- External Depth: 4.8mm
- External Length / Height: 40.4mm
- External Width: 8.4mm
- Lead Diameter: 0.8mm
- Lead Length: 32mm
- No. of Pins: 2Pins
- Operating Temperature Range: -25°C to +105°C
- Voltage Rating V DC: 3000V
